SPA CYCLES Elan Ti Gravel GRX RX820/Hope 12 Speed Hydraulic

SPA CYCLES Elan Ti Gravel click to zoom image
SPA CYCLES Elan Ti Gravel click to zoom image
SPA CYCLES Elan Ti Gravel click to zoom image
SPA CYCLES Elan Ti Gravel click to zoom image
SPA CYCLES Elan Ti Gravel click to zoom image
SPA CYCLES Elan Ti Gravel click to zoom image

New for the 2024 season, Shimano's long-awaited 12spd Non-Di2 GRX RX820 Groupset. With Re-profiled Brake/STI Levers which aid smaller hands, and Re-Configured Disc Calipers to eliminate rotor rub; we are sure that this will be a popular option on our Custom-Built Bikes.

We thought that our Elan Ti Gravel Bike deserved an upgrade option, so check out this RX820/Hope-equipped version and imagine it in a mixture of red, blue, orange & purple!

All bikes are built to order, so the spec can be varied to suit the customers requirements.
Deposits are Non-Refundable

Titanium finishing kit upgrade

Upgrade to an Ora titanium seatpost for just £85 or couple it with a titanium stem for £140. Add Ti headset spacers £2 each.
Just add a note in the Comments section when ordering your bike
Pricing
rrp £3865.00
Sale £3485.00
Model Year GRX RX820/Hope 12 Speed Hydraulic
Options 50cm CURRENTLY UNAVAILABLE
52cm
54cm
56cm
58cm
60cm
Style A so contemporary take on our Titanium Elan Mk2. A frameset designed for a gravel bike, with its relaxed stack height and generous top tube length. We've added carbon forks with carrying capacity, a wide-ranging 1x transmission, and bars with just that right amount of flare. Handbuilt, tubeless-tyred wheels will guarantee a lively, but surefooted ride without those twitchy surprises. Mudguards are optional!
Frame Elan Mk2 (142x12mm Thru-Axle) 3Al/2.5V Titanium. Bright brushed finish with shot blasted graphics
Frame Warranty 10 Year to Original Owner
Frameset has clearance for 700x40mm with full mudguards or 700x45mm without.
Forks Spa Carbon Gravel Forks (100x12mm Thru-Axle)
Rear Derailleur Shimano GRX RD-RX822 GS (10-45) or SGS (10-51)
Front Derailleur N/A
Shifters Shimano GRX ST-RX820 Hydraulic (Right hand)
Chainset Shimano GRX FC-RX820 170, 172.5 or 175mm Cranks with 40T or 42T Chainring.
Hope RX Cranks (170, 172.5 or 175mm) with Spiderless Chainring (38, 40, 42 or 44t) +£245 (includes Hope 30mm BB)
Bottom Bracket Shimano BB-R60
Chain KMC 12spd X12
Freewheel Shimano XT CS-M8100 12spd (10-45 or 10-51)
Headset Hope Pick n'Mix plus Hope Head Doctor
Stem FSA Omega OS-167 (60-130mm)
Handlebars FSA Adventure Compact 12 deg Flare (38-46cm)
Front Brake Shimano GRX BR-RX820 Hydraulic

Rear Brake Shimano GRX BR-RX820 Hydraulic

Brake Levers Shimano GRX BL-RX820 Hydraulic (Left hand)
Tyres Schwalbe G-One AllRound Raceguard Tubeless
(700 x 35C or 700 x 40C)
Teravail Cannonball or Washburn, Black or Tan Wall, 700 x 38C or 700 x 42C (+£32)
Saddle Brooks Cambium All-Weather C15, C17 or C19, Full-Top or Carved
Seatpost FSA SL-281 27.2mm
Pedals None
Miscellaneous SKS CAB Mudguards (+£25)
Forget the fashion; you know they make sense!
Wheelset Kinlin XR-26RTS Rims on Hope Pro5 Cartridge-bearing Centre-lock hubs. Black Sapim stainless steel spokes. Choice of drillings available.
Wheel size 700C
As with any product, specification is subject to change without prior notification. You are advised to confirm current specification before buying.
